Prestige 128IMH ISDN Modem/ Router/Hub
10-4 Filter Configuration
Figure 10-3 Menu 21.1 - Filter Rules Summary
10.2.1 Filter Rules Summary Menu
This screen shows the summary of the existing rules in the filter set. The following tables contain
a brief description of the abbreviations used in Menu 21.1.
Table 10-1 Abbreviations Used in the Filter Rules Summary Menu
Abbreviations Description Display
# Refers to the filter rule number (1-6).
A Refers to Active. [Y] means the filter rule is active.
[N] means the filter rule is inactive.
Type Refers to the type of filter rule.
This shows GEN for generic, IP for
TCP/IP and IPX for Novell IPX.
[GEN] for Generic
[IP] for TCP/IP
[IPX] for Novell IPX
Menu 21.1 - Filter Rules Summary
# A Type Filter Rules M m n
- - ---- -------------------------------------------- --------- - - -
1 N
2 N
3 N
4 N
5 N
6 N
Enter Filter Rule Number (1 -6) to Configure:
