VSG-1000 Vantage Service Gateway
5-8 Subscriber Control
5.2.6 Subscriber Pop-up Logout Window
When this feature is activated for RADIUS management type, the pop-up logout window displays how long the
subscriber has accessed or has yet to access the Internet depending on the accounting method you select and the
remote RADIUS server settings. When a subscriber terminates the Internet connection, a message is sent to the
RADIUS server to stop the accounting process and update the accounting information.
The following table summarizes the different logout windows and the configuration options in the Subscriber
Control screen. When applicable, a subscriber clicks Logout to terminate the Internet connection and log out.
Table 5-6 Subscriber Pop-up Logout Windows Variations
ACCOUNTING TYPE
FIELD
RADIUS SERVER
SESSION TIMEOUT
MESSAGE
LOGOUT WINDOW EXAMPLE
Time to Finish Yes
Figure 5-7 Subscriber Logout Window: Version 1
Accumulation Yes
Figure 5-8 Subscriber Logout Window: Version 2
