ZyWALL 10~100 Series Internet Security Gateway
Hardware Installation 2-7
Other ZyWALL models have an uplink button that allows you to switch
When the ZyWALL is on and properly connected to a computer or a hub, the
corresponding LAN LED on the front panel turns on.
Table 2-2 LAN Port Connections With an Uplink Button
CABLE FOR CONNECTING TO: A COMPUTER A HUB
UPLINK button “on” (pushed in) Straight-through Ethernet cable Crossover Ethernet cable
UPLINK button “off” (out) Crossover Ethernet cable Straight-through Ethernet cable
2.2.6 Connecting the Wireless LAN
Make sure the ZyWALL is turned off before inserting or removing an 11 Mbps 802.11b-compliant wireless
LAN PCMCIA card (to avoid damage). Do not insert or remove the card with the ZyWALL turned on. This
feature is not available on all models. Use the PCMCIA card release button (on models that have one) when
you remove a PCMCIA card from the slot.
Slide the 64-pin connector end of the PCMCIA wireless LAN card into the slot. See Figure 2-9 for an
example.
