ZyWALL 10~100 Series Internet Security Gateway
Remote Node Setup 10-11
10.3.2 Editing TCP/IP Options (with PPPoE Encapsulation)
Make sure Encapsulation is set to PPPoE in menu 11.1. Move the cursor to the Edit IP field in Menu
11.1 and press [SPACE BAR] to select Yes. Press [ENTER]
to open Menu 11.3 - Network Layer
Options. The menu and fields are the same as described for PPTP encapsulation above.
10.4 Remote Node Filter
Move the cursor to the field Edit Filter Sets in menu 11.1, and then press [SPACE BAR] to set the value
to Yes. Press [ENTER] to open Menu 11.5 - Remote Node Filter.
Use menu 11.5 to specify the filter set(s) to apply to the incoming and outgoing traffic between this remote
node and the ZyWALL to prevent certain packets from triggering calls. You can specify up to 4 filter sets
separated by commas, for example, 1, 5, 9, 12, in each filter field. Note that spaces are accepted in this
field. For more information on defining the filters, please refer to the Filters chapter. For PPPoE or PPTP
encapsulation, you have the additional option of specifying remote node call filter sets.
Figure 10-7 Menu 11.5: Remote Node Filter (Ethernet Encapsulation)
Menu 11.5 - Remote Node Filter
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Enter here to CONFIRM or ESC to CANCEL:
