ZyWALL 10~100 Series Internet Security Gateway
Bandwidth Management 25-17
Table 25-6 Bandwidth Management Statistics
FIELD DESCRIPTION
Class Name This field displays the name of the class the statistics page is showing.
Budget (kbps) This field displays the amount of bandwidth allocated to the class.
Tx Packets This field displays the total number of packets transmitted.
TX Bytes This field displays the total number of bytes transmitted.
Dropped Packets This field displays the total number of packets dropped.
Dropped Bytes This field displays the total number of bytes dropped.
Bandwidth Statistics for the Past 8 Seconds (t-8 to t-1)
This field displays the bandwidth statistics (in bps) for the past one to eight seconds. For example, t-1 means
one second ago.
Update Period
(seconds) Enter the time interval in seconds to define how often the information should be
refreshed.
Set Interval
Click Set Interval to apply the new update period you entered in the Update Period
field above.
Stop Update
Click Stop Update to stop the browser from refreshing bandwidth management
statistics.
Clear Counter Click Clear Counter to clear all of the bandwidth management statistics.
25.8.5 Bandwidth Manager Monitor
Use the Bandwidth Manager Monitor screen to view the device’s bandwidth usage and allotments.
Click Advanced, BW Manager, and then the Monitor tab to open the following screen.
