ZyWALL 10~100 Series Internet Security Gateway
Hardware Installation 2-3
Table 2-1 LED Descriptions
LED COLOR STATUS MEANING
Orange Off The 100M DMZ is not connected.
On The ZyWALL is connected to a 100Mbps DMZ.
DMZ
100M
Flashing The 100M DMZ is sending or receiving packets.
Off The 10M WAN link is not ready, or has failed.
On The 10M WAN link is OK.
WAN 10M Green
Flashing The 10M WAN link is sending or receiving packets.
Off The 100M WAN link is not ready, or has failed.
On The 100M WAN link is OK.
WAN
100M Orange
Flashing The 100M WAN link is sending or receiving
packets.
Off The backup port is not connected. AUX LNK Green
On The backup port is connected.
Off The auxiliary port is not sending or receiving
packets. AUX ACT Green
Flashing The auxiliary port is sending or receiving packets.
CON/AUX Off The CON/AUX link is not ready, or has failed. Green
On The CON/AUX switch is set to CON and the
CON/AUX port is connected to a management
computer.
Orange Off The CON/AUX link is not ready, or has failed.
On The CON/AUX switch is set to AUX and the
CON/AUX port has an Internet connection through
a dial-up modem.
Flashing The CON/AUX switch is set to AUX and the
CON/AUX port is sending or receiving data through
a dial-up modem.
2.2 ZyWALL Rear Panel and Connections
The following figure shows the rear panels of the ZyWALL.
