Appendix A - 230 VAC Power Cord
230 VAC Power Cord
Depending on how the Zebra printer was ordered, a power cord may or
may not be included when the printer is optioned for 230 VAC,
50/60 Hz operation.
If a power cord is not supplied, you will need to obtain one with the fol-
lowing specifications:
• The overall length must be less than 3.8 meters.
• It must be rated for at least 5 amps, 250 V.
• The CHASSIS GROUND (EARTH) MUST BE CONNECTED to
assure safety and reduce electromagnetic interference. This is done
by the third wire in the power cord.
• The plug cap should bear the certification mark of a known interna-
tional safety organization (see Figure A.2).
Zebra S-Series User’s Guide A-1
Figure A.1 AC Power Cord
Figure A.2 International Safety Organizations
85
