If your media is not wide enough, the test labels will only print
out to the edge of the label. If your media is too short, the test
label will continue printing on the next label.
Some of the printer self tests produce labels at varying print speeds.
These speeds may be referred to as “inches per second,” “millimeters
per second,” or by alphabetic letter designation (i.e., “A,” “B,” “C,”
etc.). The following chart shows the relationships between the different
speeds.
Letter
Designation English Metric
A* 2"/sec. 51 mm/sec.
B 3"/sec. 76 mm/sec.
C 4"/sec. 102 mm/sec.
5"/sec. 127 mm/sec.
D 6"/sec. 152 mm/sec.
* Speed “A” for the 105Se with the optional 300 dots-per-inch print-
head is 2.4" (61 mm).
3-8 Zebra S-Series User’s Guide
