Data Specifications
When communicating via the serial data port (RS-232), the baud rate,
number of data bits, and the parity are user-selectable (see
for acceptable setting combinations). Parity only
applies to data transmitted by the printer, since it ignores the parity of re-
ceived data. The S-Series Printer is fixed at 1 stop bit, so make sure that your
host is also set at 1 stop bit.
When communicating via the parallel port, the previously mentioned
parameters are not considered.
RS-232 Serial Data Port
The connections for the standard interface are made through the DB25S
connector on the rear panel. For all RS-232 input and output signals,the
S-SeriesPrinterfollowsboththeElectronics Industries Association’s (EIA)
RS-232 and the Consultative Committee for International Telegraph and Tele-
phone (CCITT) V.24 standard signal level specifications.
5-2
Zebra S-Series User’s Guide
Pin No.
Description
1
Frame Ground for Cable Shield
2
TXD (Transmit Data) output from the printer
3
RXD (Receive Data) input to the printer
4
RTS (Request To Send) output from the printer
6
DSR (Data Set Ready) input to the printer
7
Signal Ground
20
DTR (Data Terminal Ready) output from the printer
Note:
Pins 5, 8, 10-19, and 21-25 are not used and are unterminated.
Table 5.1 RS-232 Pinouts
