Chapter 17 Queuing Method
GS-2024 User’s Guide
124
17.2 Configuring Queuing
Click Advanced Application > Queuing Method in the navigation panel.
Figure 60 Advanced Application > Queuing Method
The following table describes the labels in this screen.
Table 37 Advanced Application > Queuing Method
LABEL DESCRIPTION
Method Select SPQ (Strictly Priority Queuing) or WRR (Weighted Round Robin).
Strictly Priority services queues based on priority only. When the highest priority queue
empties, traffic on the next highest-priority queue begins. Q7 has the highest priority and
Q0 the lowest.
Weighted Round Robin Scheduling services queues on a rotating basis based on their
queue weight (the number you configure in the queue Weight field). Queues with larger
weights get more service than queues with smaller weights.
Q0-Q3
Weight
This field is applicable only when you select WRR.
When you select WRR enter the queue weight here. Bandwidth is divided across the
different traffic queues according to their weights.
Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch loses
these changes if it is turned off or loses power, so use the Save link on the top navigation
panel to save your changes to the non-volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
