Chapter 14 Link Aggregation
GS-2024 User’s Guide
116
Figure 54 Trunking Example - Physical Connections
2 Configure static trunking - Click Advanced Application > Link Aggregation > Link
Aggregation Setting. In this screen activate trunking group T1 and select the ports that
should belong to this group as shown in the figure below. Click Apply when you are
done.
Figure 55 Trunking Example - Configuration Screen
Your trunk group 1 (T1) configuration is now complete; you do not need to go to any
additional screens.
A
B
example
