MicroBlaze Development Kit Spartan-3E 1600 Edition User Guide

87

UG257 (v1.1) December 5, 2007

www.xilinx.com

Shared Connections

R

Shared Connections

Besides the connections to the FPGA, the StrataFlash memory shares some connections to

other components.

Character LCD

The LCD supports an 8-bit or a 4-bit data interface. The eight display data connections are

also shared with the SF_D<15:8> signals on the StrataFlash PROM. As shown in

Table 11-2

,

the FPGA controls access to the StrataFlash PROM or the character LCD using the SF_CE0

and LCD_RW signals.

Xilinx XC2C64A CPLD

The Xilinx XC2C64A CoolRunner CPLD controls the five upper StrataFlash address lines,

SF_A<24:20> during configuration. The four upper BPI-mode address lines from the

FPGA, A<23:20> are not connected. Instead, four FPGA user-I/O pins connect to the

StrataFlash PROM upper address lines SF_A<23:0>. See

Chapter 16, “XC2C64A

CoolRunner-II CPLD”

for more information.

The most-significant address line, SF_A<24>, is not physically used on the 16 Mbyte

StrataFlash PROM. It is provided for upward migration to a larger StrataFlash PROM in

the same package footprint. Likewsie, the SF_A<24> signal is also connected to the

FX2_IO<32> signal on the FX2 expansion connector.

SPI Data Line

The least-significant StrataFlash data line, SF_D<0>, is shared with data output signals
from serial SPI peripherals, SPI_MISO, and the serial output from the Platform Flash

PROM as shown in

Table 11-3

. To avoid contention, the FPGA application must ensure that

only one data source is active at any time.

Table 11-2:

FPGA Control for StrataFlash and LCD

SF_CE0

LCD_RW

Function

1

1

The FPGA reads from the character LCD.

0

0

The FPGA accesses the StrataFlash PROM.

Table 11-3:

Possible Contention on SPI_MISO (SF_D<0>) Data

Condition

Function

FPGA_M2 = Low
FPGA_M1 = Low
FPGA_M0 = Low
INIT_B = High

Platform Flash outputs data on D0.

SF_CE0 = Low
SF_OE = Low

StrataFlash outputs data.

AD_CONV = High
SPI_SCK

Serial data is clocked out of the A/D converter

DAC_CS = Low
SPI_SCK

DAC outputs previous command in response to SPI_SCK transitions.
