MicroBlaze Development Kit Spartan-3E 1600 Edition User Guide
159
UG257 (v1.1) December 5, 2007
www.xilinx.com
DDR SDRAM Series Termination and FX2 Connector Differential Termination
R
Figure 18-13:
Schematic Sheet 14
UG257_A13_060606
