Troubleshooting

12-8

WorkCentre Pro 555/575

Status Code Table

A status code is displayed on some reports. The Code is displayed in
3 digits to the right of the Mode symbol.

Code

Transmission
Speed

Code

Line Density

Code

Encoding

0

2400 bps

0

8 pels/mm x 3.85 lines/mm

0

MH

1

4800 bps

1

8 pels/mm x 7.7lines/mm

1

MR

2

7200 bps

2

8 pels/mm x 15.4 lines/mm

2

MMR

3

9600 bps

3

—

3

JBIG

4

12000 bps

4

16 pels/mm x 15.4 lines/mm

5

14400 bps

6

33600 bps

G3

Encoded Data
Line Density Data
Transmission Speed

G3

MMR
8 pels/mm x 3.85/lines/mm
14400 bps

5 0 2

Example:

CODE
