Chapter 6 WAN Setup
P-660HN-TxA User’s Guide
75
6.2 The Internet Access Setup Screen
Use this screen to change your ZyXEL Device’s WAN settings. Click Network >
WAN > Internet Access Setup. The screen differs by the WAN type and
encapsulation you select.
Figure 30 Network > WAN >Internet Access Setup (PPPoE)
The following table describes the labels in this screen.
Table 16 Network > WAN > Internet Access Setup
LABEL DESCRIPTION
Line
ADSL Mode
Select the mode supported by your ISP.
Use Auto Sync-Up if you are not sure which mode to choose from.
The ZyXEL Device dynamically diagnoses the mode supported by the
ISP and selects the best compatible one for your connection.
Other options are ADSL2+, ADSL2, G.DMT, T1.413 and G.lite.
ADSL Type Select the type supported by your ISP.
Available options are ANNEX A, ANNEX A/L, ANNEX M and ANNEX
A/L/M.
