ViewSonic PJ1165 18
Adjusting The Picture Position
memo
This function is available only for RGB signals.
Correcting The Keystone Distortion
1 Press the POSITION button.
As illustrated on the right, a dialog
will appear on the screen to aid you
in adjusting the picture position.
2 Use the cursor buttons S/T/W/X to
adjust the position.
memo
When you want to initialize the position, press the
RESET button during adjustment.
3 Press the POSITION button again to close the dialo and
complete this operation.
memo
Even if you don’t do anything, the dialog will
automatically disappear after a few seconds.
1 Press the KEYSTONE button.
As illustrated on the right, a dialog will appear
on the screen to aid you in correcting the
keystone distortion.
2 Use the cursor buttons W/X to select the
direction of distortion to correct (
or ).
3 Use the cursor buttons S/T to correct the distortion.
4 Press the KEYSTONE button again to close the dialog and
complete this operation.
memo
Even if you don’t do anything, the dialog will
automatically disappear after a few seconds.
Cursor
buttons
POSITION
button
RESET
button
Cursor
buttons
KEYSTONE
button
