2-24
Installation
Installing Standalone Units
Enclosure Resting
on Cover
Figure 2-4 shows the bottom of the standalone enclosure.
Figure 2-4. Bottom of Standalone Enclosure
Locking Tab Slots
Locking Tab Slots
Plastic Locking Clip
Squeeze
