1-14 About the 6500
PLUS
Hardware
NSO Card Figure 1-5 shows the NSO card.
Figure 1-5. 6500
PLUS
Network Storage Option Card
6500 NSO
TEST
P.C. 68908
MEM1
MEM3
MEM5
TEST (Red)
Indicates status of internal tests.
On: Test failed
Off: Normal condition
Flashing: Test in progress
MEM (Yellow)
Indicates amount of memory
available on this card
MEM 1: 1 Mbyte RAM
MEM 3: 3 Mbyte RAM
MEM 5: 5 Mbyte RAM
DISK
On when disk is being accessed.
