It is possible to control the amount of
bandwidth used on calls between specific
subzones and zones. The limits can be
applied to the total concurrent bandwidth used
at any one time, or to the bandwidth used by
any individual call.
To apply these limits, you create a pipe and
configure it with the required bandwidth
limitations. You then assign the pipe to a
link. Calls using the link will then have those
bandwidth limitations applied to them.

Creating Pipes

Name

Enter the name you wish to give to this pipe.
You will refer to this name when creating links.

Create Pipe

Click here to create the pipe and return to the

Pipes

page.

About Pipes

Creating a new pipe

To create a pipe:

VCS Configuration > Bandwidth > Pipes

You will be taken to the

Pipes

page.

Select

New

You will be taken to the

Create Pipe

page.

xCommand PipeAdd

•

Total bandwidth mode

Determines whether there is a limit on the
total concurrent bandwidth of this pipe.

Unlimited

: no limitations are in place.

Limited

: there is a limit in place; you must

enter the limit in the field below.

None

: there is no bandwidth available.

Total bandwidth (kbps)

Sets the limit on the total concurrent
bandwidth of this pipe.

Per call bandwidth mode

Determines whether there is a limit on the
bandwidth of individual calls via this pipe.

Unlimited

: no limitations are in place.

Limited

: there is a limit in place; you must

enter the limit in the field below.

None

: there is no bandwidth available.

Per call bandwidth (kbps)

Sets the limit on the bandwidth of individual
calls via this pipe.
