2.11.32 Output Formatter 6 Register
Subaddress
38h
Default
FFh
7
6
5
4
3
2
1
0
C_9 [1:0]
C_8 [1:0]
C_7 [1:0]
C_6 [1:0]
C_9 [1:0]: C_9 terminal function select
00 = C_9 is logic 0 output.
01 = C_9 is logic 1 output.
10 = Reserved
11 = C_9 is logic input (default).
C_8 [1:0]: C_8 terminal function select
00 = C_8 is logic 0 output.
01 = C_8 is logic 1 output.
10 = Reserved
11 = C_8 is logic input (default).
C_7 [1:0]: C_7 terminal function select
00 = C_7 is logic 0 output.
01 = C_7 is logic 1 output.
10 = Reserved
11 = C_7 is logic input (default).
C_6 [1:0]: C_6 terminal function select
00 = C_6 is logic 0 output.
01 = C_6 is logic 1 output.
10 = Reserved
11 = C_6 is logic input (default).
C_x functions are only available in the 10-bit output mode.
2.11.33 Clear Lost Lock Detect Register
Subaddress
39h
Default
00h
7
6
5
4
3
2
1
0
Reserved
Clear lost lock detect
Clear lost lock detect: Clear bit 4 (lost lock detect) in the status 1 register at subaddress 3Ah (see Section
2.11.34)
0 = No effect (default)
1 = Clears bit 4 in the status 1 register
