Functional Description
29 SLES140A—March 2007 TVP5147M1PFP
Table 2−10. I 2 C Register Summary (Continued)
REGISTER NAME I2C SUBADDRESS DEFAULT R/W
F and V bit control 75h 12h R/W
VCR trick mode control 76h 8Ah R/W
Horizontal shake increment 77h 64h R/W
AGC increment speed 78h 05h R/W
AGC increment delay 79h 1Eh R/W
Reserved 7Ah−7Eh
Analog output control 1 7Fh 00h R/W
Chip ID MSB 80h 51h R
Chip ID LSB 81h 47h R
Reserved 82h
CPLL speed control 83h 09h R/W
Reserved 84h−96h
Status request 97h 00h R/W
Reserved 98h−99h
Vertical line count 9Ah−9Bh R
Reserved 9Ch−9Dh
AGC decrement delay 9Eh 00h R/W
Reserved 9Fh−B0h
VDP TTX filter 1 mask 1 B1h 00h R/W
VDP TTX filter 1 mask 2 B2h 00h R/W
VDP TTX filter 1 mask 3 B3h 00h R/W
VDP TTX filter 1 mask 4 B4h 00h R/W
VDP TTX filter 1 mask 5 B5h 00h R/W
VDP TTX filter 2 mask 1 B6h 00h R/W
VDP TTX filter 2 mask 2 B7h 00h R/W
VDP TTX filter 2 mask 3 B8h 00h R/W
VDP TTX filter 2 mask 4 B9h 00h R/W
VDP TTX filter 2 mask 5 BAh 00h R/W
VDP TTX filter control BBh 00h R/W
VDP FIFO word count BCh R
VDP FIFO interrupt threshold BDh 80h R/W
Reserved BEh
VDP FIFO reset BFh 00h R/W
VDP FIFO output control C0h 00h R/W
VDP line number interrupt C1h 00h R/W
VDP pixel alignment C2h−C3h 01Eh R/W
Reserved C4h−D5h
VDP line start D6h 06h R/W
VDP line stop D7h 1Bh R/W
VDP global line mode D8h FFh R/W
VDP full field enable D9h 00h R/W
VDP full field mode DAh FFh R/W
Reserved DBh−DFh
NOTE: R = Read only
W = Write only
R/W = Read and write
Reserved register addresses must not be written to.
