Functional Description
16 SLES140A—March 2007 TVP5147M1PFP
Table 2−1. Output Format
TERMINAL
NAME
TERMINAL
NUMBER
10-Bit 4:2:2
YCbCr
20-Bit 4:2:2
YCbCr
Y_9 43 Cb9, Y9, Cr9 Y9
Y_8 44 Cb8, Y8, Cr8 Y8
Y_7 45 Cb7, Y7, Cr7 Y7
Y_6 46 Cb6, Y6, Cr6 Y6
Y_5 47 Cb5, Y5, Cr5 Y5
Y_4 50 Cb4, Y4, Cr4 Y4
Y_3 51 Cb3, Y3, Cr3 Y3
Y_2 52 Cb2, Y2, Cr2 Y2
Y_1 53 Cb1, Y1, Cr1 Y1
Y_0 54 Cb0, Y0, Cr0 Y0
C_9 57 Cb9, Cr9
C_8 58 Cb8, Cr8
C_7 59 Cb7, Cr7
C_6 60 Cb6, Cr6
C_5 63 Cb5, Cr5
C_4 64 Cb4, Cr4
C_3 65 Cb3, Cr3
C_2 66 Cb2, Cr2
C_1 69 Cb1, Cr1
C_0 70 Cb0, Cr0
Table 2−2. Summary of Line Frequencies, Data Rates, and Pixel/Line Counts
STANDARDS
PIXELS PER
LINE
ACTIVE PIXELS
PER LINE
LINES PER
FRAME
PIXEL
FREQUENCY
(MHz)
COLOR
SUBCARRIER
FREQUENCY (MHz)
HORIZONTAL
LINE RATE (kHz)
601 sampling
NTSC-J, M 858 720 525 13.5 3.579545 15.73426
NTSC-4.43 858 720 525 13.5 4.43361875 15.73426
PAL-M 858 720 525 13.5 3.57561149 15.73426
PAL-60 858 720 525 13.5 4.43361875 15.73426
PAL-B, D, G, H, I 864 720 625 13.5 4.43361875 15.625
PAL-N 864 720 625 13.5 4.43361875 15.625
PAL-Nc 864 720 625 13.5 3.58205625 15.625
SECAM 864 720 625 13.5
Dr = 4.406250
Db = 4.250000
15.625
2.5.1 Separate Syncs
VS, HS, and VBLK are independently software programmable to a 1
×
pixel count. This allows any possible
alignment to the internal pixel count and line count. The default settings for 525-line and 625-line video outputs
are given as examples below. FID changes at the same transient time when the trailing edge of vertical sync
occurs. The polarity of FID is programmable by an I
2 C interface.
