TANDBERG GW

Dataport Command Interface User Guide

D13202 Rev 01

4

2.

Connecting to the Dataport Command Interface through the
RS-232 port.

The RS-232 port is a 9-pin, female, D-sub connector located on the back of the GW. The port
is configured as a DCE (Data Communications Equipment). The RS-232 port is default set to
9600 baud, 8 databits, none parity and 1 stopbit from factory. The RS-232 port is also referred
to as the Dataport.

2.1.

Hardware And Cabling

The pin outs for the RS-232 are defined in the following table (the DTE, Data Terminal
Equipment, could be a PC or other device capable of serial communication).

Pin no

Signal

Description

Direction

1

CD

Carrier detect

To DTE

2 RD

Receive

data

To

DTE

3 TD

Transmit

data

From

DTE

4

DTR

Data terminal ready

From DTE

5

Ground

6

DSR

Data set ready

To DTE

7

RTS

Ready to send

From DTE

8

CTS

Clear to send

To DTE

9

RI

Ring indicator

To DTE

NOTE! A straight through cable should be used between the TANDBERG GW’s RS-232 port
and the DTE.

The figure below illustrates the recommended cable-wiring scheme for connecting the GW to
a PC through RS-232.

DTR and RTS are ignored. DSR, CD, and CTS are always asserted, while RI is not used.

TANDBERG GW

PC

DCE, 9 pin

DTE, 9 pin

1 CD

1 CD

2 RD

2 RD

3 TD

3 TD

4 DTR

4 DTR

5 GND

5 GND

6 DSR

6 DSR

7 RTS

7 RTS

8 CTS

8 CTS

9 RI

9 RI
