Ethernet Media Access Controller (EMAC) Registers
5.10 Transmit Interrupt Mask Clear Register (TXINTMASKCLEAR)
The transmit interrupt mask clear register (TXINTMASKCLEAR) is shown in
and described in
.
Figure 49. Transmit Interrupt Mask Clear Register (TXINTMASKCLEAR)
31
16
Reserved
R-0
15
8
Reserved
R-0
7
6
5
4
3
2
1
0
TX7MASK
TX6MASK
TX5MASK
TX4MASK
TX3MASK
TX2MASK
TX1MASK
TX0MASK
R/W1C-0
R/W1C-0
R/W1C-0
R/W1C-0
R/W1C-0
R/W1C-0
R/W1C-0
R/W1C-0
LEGEND: R = Read only; R/W = Read/Write; W1C = Write 1 to clear, write of 0 has no effect; -n = value after reset
Table 47. Transmit Interrupt Mask Clear Register (TXINTMASKCLEAR) Field Descriptions
Bit
Field
Value
Description
31-8
Reserved
0
Reserved
7
TX7MASK
0-1
Transmit channel 7 interrupt mask clear bit. Write 1 to disable interrupt, a write of 0 has no effect.
6
TX6MASK
0-1
Transmit channel 6 interrupt mask clear bit. Write 1 to disable interrupt, a write of 0 has no effect.
5
TX5MASK
0-1
Transmit channel 5 interrupt mask clear bit. Write 1 to disable interrupt, a write of 0 has no effect.
4
TX4MASK
0-1
Transmit channel 4 interrupt mask clear bit. Write 1 to disable interrupt, a write of 0 has no effect.
3
TX3MASK
0-1
Transmit channel 3 interrupt mask clear bit. Write 1 to disable interrupt, a write of 0 has no effect.
2
TX2MASK
0-1
Transmit channel 2 interrupt mask clear bit. Write 1 to disable interrupt, a write of 0 has no effect.
1
TX1MASK
0-1
Transmit channel 1 interrupt mask clear bit. Write 1 to disable interrupt, a write of 0 has no effect.
0
TX0MASK
0-1
Transmit channel 0 interrupt mask clear bit. Write 1 to disable interrupt, a write of 0 has no effect.
