Connecting a Cassette, CDR, MiniDisc, or DAT Recorder
Connection
AV receiver
Signal flow
Cassette, CDR, MD, or DAT recorder
TV/TAPE IN L/R
TV/TAPE OUT L/R
⇐
⇒
Analog audio L/R output
Analog audio L/R input
DIGITAL IN COAXIAL 2 (CBL/SAT)
⇐
Digital coaxial output
DIGITAL IN OPTICAL 1 (TV/TAPE)
⇐
Digital optical output
COAXIAL
OUT
AUDIO
IN
L
R
OPTICAL
OUT
AUDIO
OUT
L
R
b
c
a
a
Step 1:
Choose a connection that matches your recorder (
,
, or
), and then make the connection.
a
b
c
Cassette, CDR, MD, etc.
Connect one or the other
These connections must be
assigned (see page 43)
a
a
b
a
c
a
b
c
