4.0 Electrical & Mechanical Specifications
4.6 Microcomputer Interface Timing
Bt8960
Single-Chip 2B1Q Transceiver
N8960DSB
Figure 4-6. MCI Write Timing, Intel Mode (MOTEL = 0)
Write
Strobe
ALE
35
36
37
34
39
41
42
Address
Data (Input)
45
AD[7:0]
or
ADDR[7:0]
READY
58
59
48
Figure 4-7. MCI Write Timing, Motorola Mode (MOTEL = 1)
AD[7:0]
Write
Strobe
ALE
35
36
37
34
39
41
42
R/W
43
44
Address
Data (Input)
45
58
59
or
ADDR[7:0]
READY
48
