Registers Register Summar
y
Bt8960
Single-Chip 2B1Q T
ransceiver
42
N8960DSB
0x4C ber_meter_low R/W D[7] D[6] D[5] D[4] D[3] D[2] D[1] D[0]
0x4D ber_meter_high R/W D[15] D[14] D[13] D[12] D[11] D[10] D[9] D[8]
0x4E symbol_histogram R/W D[7] D[6] D[5] D[4] D[3] D[2] D[1] D[0]
0x50 nlm_low R/W D[23] D[22] D[21] D[20] D[19] D[18] D[17] D[16]
0x51 nlm_high R/W D[31] D[30] D[29] D[28] D[27] D[26] D[25] D[24]
0x5E pll_frequency_low R/W D[22] D[21] D[20] D[19] D[18] D[17] D[16] D[15]
0x5F pll_frequency_high R/W D[30] D[29] D[28] D[27] D[26] D[25] D[24] D[23]
0x70 linear_ec_tap_select_read R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
0x71 linear_ec_tap_select_write R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
0x72 nonlinear_ec_tap_select_read R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
0x73 nonlinear_ec_tap_select_write R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
0x74 dfe_tap_select_read R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
0x75 dfe_tap_select_write R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
0x76 sp_tap_select_read R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
0x77 sp_tap_select_write R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
0x78 eq_add_read R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
0x79 eq_add_write R/W — — D[5] D[4] D[3] D[2] D[1] D[0]
Table 3-1. Register Table (5 of 6)
ADDR
(hex)
Register
Label
Read
Write
Bit Number
7 6 5 4 3 2 1 0
