72
4.0 Electrical & Mechanical Specifications
4.2 Recommended Operating Conditions
Bt8960
Single-Chip 2B1Q Transceiver
N8960DSB
4.2 Recommended Operating Conditions
Table 4-2. Recommended Operating Conditions
Symbol Parameter Minimum Typical Maximum Units
V
DD1
Digital Core-Logic Supply Voltage 4.75 5.0 5.25 V
V
DD2
Digital I/O-Buffer Supply Voltage 4.75 5.0 5.25 V
V
AA
Analog Supply Voltage 4.75 5.0 5.25 V
V
IH
High-Level Input Voltage 2.0 V
DD2
+ 0.3 V
V
IL
Low-Level Input Voltage –0.3 +0.8 V
V
IHX
High-Level Input Voltage for XTALI / MCLK 0.8*V
DD2
V
DD2
+ 0.3 V
V
ILX
Low-Level Input Voltage for XTALI / MCLK –0.3 0.2*V
DD2
V
C
L
Output Capacitive Loading (1) 60 pF
T
A Ambient Operating Temperature (2) –40 +85 ˚C
Notes: (1). Capacitive loading over which all digital output switching characteristics are guaranteed.
(2). Still-air temperature range over which all electrical characteristics and timing requirements/characteristics are guaran-
teed.
