Page 33
Regency
®
P40-1 Direct Vent Gas Fireplace
33
INST
ALLA
TION
INSTALLATION
11)
Place log 03-33 on the back burner in between the burner tubes.
Slide the log to the left until it touches the end of the burner tube.
03-33
Burner
Tube
10)
Fit log 03-34 into the 1st log stand post and rest on the ember bed.
1st Log
Stand Post
03-34
03-40
6)
Spread rockwool along the back side of the front burner tube as
shown. Ensure not to cover burner ports.
7)
Place lava rock in between the rockwool along the back side of the
front burner tube as shown. Ensure not to cover burner ports.
9)
Spread vermiculite on the exposed base brick in front of the front
burner tube and on the log stand as shown. Ensure not to cover
burner ports.
03-40
03-34
03-33
8)
Separate platinum embers and place on and around the embers on
the front burner. Avoid stacking platinum embers. Platinum embers
can be placed over burner ports.
