218
Specifications
CDX-1:
MULTITRACK CD RECORDER /
AUDIO SAMPLE WORKSTATION
● Audio Data Format
CDX-1 Original Format (R-DAC)
● Maximum Polyphony
Monaural x 8 (Stereo x 4) (Total)
● Audio Tracks
Number of Tracks: 8
Maximum Simultaneously Playback
Tracks: 8
Maximum Simultaneously Recording
Tracks: 2
Data Type: STANDARD
LONG 1
LONG 2
Recording Time: Data Type Time
STANDARD About 15 minutes
LONG 1 About 19 minutes
LONG 2 About 23 minutes
● Audio Sample PAD
Sample PAD: 512 Phrases (8 PAD x 64 Bank)
Maximum Polyphony: 4 (Stereo/Mono)
Memory Capacity: 15 MB (*)
* When expanding the Memory (DIMM: 128 MB): 111 MB
Data Type: HIGH
STANDARD
LONG 1
LONG 2
Sampling Time: Data Type Time
HIGH About 5 minutes
STANDARD About 7 minutes
LONG 1 About 9 minutes
LONG 2 About 11 minutes
* When expanding the Memory (DIMM: 128MB):
Data Type Time
HIGH About 43 minutes
STANDARD About 58 minutes
LONG 1 About 69 minutes
LONG 2 About 87 minutes
● Maximum number of phrases (events) to be
memorized
2000 phrases
● Signal Processing
AD Conversion: 24 bits, 64 times oversampling
DA Conversion: 24 bits, 128 times oversampling
● Sample rate
44.1 kHz
● Frequency Response
20 Hz – 20 kHz (+0/-3 dB)
● Nominal Output Level (variable)
Guitar/Bass (Hi-Z): -26 dBu (SENS: MAX)
MIC 1, 2: -56 dBu (SENS: MAX)
LINE: 0 dBu (SENS: MAX)
● Input Impedance
Guitar/Bass (Hi-Z): 1M ohms
MIC 1, 2: 100k ohms
LINE: 30k ohms
● Nominal Output Level
Master Out: 0 dBu
● Output Impedance
Master Out: 1k ohms
Phones: 22 ohms
● Recommended Load Impedance
Master Out: 10 k ohms or greater
Phones: 8–600 ohms
● Residual Noise Level
Master Out: -77 dBu or less
(INPUT:LINE, ASENS: MAX, AIHF-A, typ.)
● Interface
Digital I/O: Coaxial, Optical (conforms to S/P DIF)
● Display
69.0 x 25.0 mm (backlit LCD)
● Connectors
MIC In Jack 1, 2 (1/4 inch TRS phone type)
MIC In Jack 1, 2 (XLR type)
Guitar/Bass (Hi-Z) Jack (1/4 inch phone type)
Line In Jack L/R (RCA phono type)
Digital In Connectors (Coaxial type, Optical type)
Master Out Jack L/R (RCA phono type)
Digital Out Connectors (Coaxial type, Optical type)
Phones Jack (Stereo 1/4 inch phone type)
Foot Switch Jack (1/4 inch phone type)
MIDI Connectors (In, Out/Thru)
