Riverstone Networks RS Switch Router User Guide Release 8.0 30-25
WAN Configuration WAN Configuration Examples
30.15 WAN CONFIGURATION EXAMPLES
30.15.1 Simple Configuration File
The following is an example of a simple configuration file used to test frame relay and PPP WAN ports:
For a broader, more application-oriented WAN configuration example, see "Multi-Router WAN Configuration" next.
30.15.2 Multi-Router WAN Configuration
The following is a diagram of a multi-router WAN configuration encompassing three subnets. From the diagram, you
can see that R1 is part of both Subnets 1 and 2, R2 is part of both Subnets 2 and 3, and R3 is part of subnets 1 and 3.
You can click on the router label (in blue) to jump to the actual text configuration file for that router:
port set hs.5.1 wan-encapsulation frame-relay speed 45000000
port set hs.5.2 wan-encapsulation ppp speed 45000000
interface create ip fr1 address-netmask 10.1.1.1/16 port hs.5.1.100
interface create ip ppp2 address-netmask 10.2.1.1/16 port hs.5.2
interface create ip lan1 address-netmask 10.20.1.1/16 port et.1.1
interface create ip lan2 address-netmask 10.30.1.1/16 port et.1.2
ip add route 10.10.0.0/16 gateway 10.1.1.2
ip add route 10.40.0.0/16 gateway 10.2.1.2
