Riverstone Networks RS Switch Router User Guide Release 8.0 16-13
BGP Configuration Guide BGP Configuration Examples
The example output shown above displays the number of packets and bytes sent at the interface 'int1'. The user has
sent 111 packets of size 130 bytes that fell into bucket 1 (traffic index 1). For example, a ping request (with a data size
of 84 bytes) was sent 111 times.
Use the
ip clear bgp-actg
command to clear BGP accounting statistics. For example:
If you need to see which traffic index is assigned to a route, run the following Diagnostic mode command:
16.3 BGP CONFIGURATION EXAMPLES
This section presents sample configurations illustrating BGP features. The following features are demonstrated:
• BGP peering
• Internal BGP (IBGP)
• External BGP (EBGP) multihop
• BGP community attribute
• BGP local preference (local_pref) attribute
• BGP Multi-Exit Discriminator (MED) attribute
• EBGP aggregation
• Route reflection
• BGP confederation
• Route map
rs# ip clear bgp-actg
rs# ip show interfaces int1 bgp-actg
Interface:int1
Bucket Packets Bytes
0 0 0
1 0 0
rs# diag
rs? ip find route 14.1.0.0
route to: 14.1.0.0
mask: (255) ffff ffff
interface: toRTR2
gateway: 12.1.1.2
aspath info: Next Hop - 0, Origin - 0
traffic index: 1
flags:
recvpipe sendpipe ssthresh rtt,msec rttvar hopcount mtu
16384 16384 0 0 e
