28-6 Riverstone Networks RS Switch Router User Guide Release 8.0
Configuring RMON Groups RMON Configuration
To find out which host or user is using these applications/protocols on this port, use the following command:
28.3 CONFIGURING RMON GROUPS
As mentioned previously, control tables in many RMON groups specify the data that is to be collected for the particular
RMON group. If the information you want to collect is in the default control tables, then you only need to turn on the
default tables when you specify the RMON groups (Lite, Standard, or Professional); you do not need to configure
entries in the default tables.
The following table shows the
rmon
command that you use to configure each RMON group:
rs# rmon show al-matrix et.5.5
RMON II Application Layer Host Table
Index: 500, Port: et.5.5, Inserts: 4, Deletes: 0, Owner: monitor
SrcAddr DstAddr Packets Octets Protocol
------- ------- ------- ------ --------
10.50.89.88 15.15.15.3 1771 272562 *ether2.ip-v4
10.50.89.88 15.15.15.3 1125 211192 *ether2.ip-v4.tcp
10.50.89.88 15.15.15.3 1122 210967 *ether2.ip-v4.tcp.telnet
10.50.89.88 15.15.15.3 3 225 *ether2.ip-v4.tcp.www-http
To configure the Address Map
group.
rmon address-map index port [owner
] [status enable|disable]
To configure the Application
Layer Matrix top n entries.
rmon al-matrix-top-n index matrix-index
ratebase terminal-packets|terminal-octets|
all-packets|all-octets duration size
[owner ] [status enable|disable]
To configure the Alarm group.
rmon alarm index variable [interval
] [falling-event-index ] [falling-threshold
] [owner ] [rising-event-index ]
[rising-threshold ] [startup rising|falling|both]
[status enable|disable] [type absolute-value|delta-value]
To configure the Packet Capture
group.
rmon capture index channel-index
[full-action lock|wrap] [slice-size ]
[download-slice-size ] [download-offset ]
[max-octets ] [owner ] [status
enable|disable]
