21.8.2 Dynamic Configuration
The following example configures a dynamic address binding for inside addresses 10.1.1.0/24 to outside address
192.50.20.0/24:
Figure 21-2 Dynamic address binding configuration
1. The first step is to create the interfaces:
2. Next, define the interfaces to be NAT “inside” or “outside”:
3. Then, define the NAT dynamic rules by first creating the source ACL pool and then configuring the
dynamic bindings:
interface create ip 10-net address-netmask 10.1.1.1/24 port et.2.1
interface create ip 192-net address-netmask 192.50.20.1/24 port et.2.2
nat set interface 10-net inside
nat set interface 192-net outside
acl lcl permit ip 10.1.1.0/24
nat create dynamic local-acl-pool lcl global-pool 192.50.20.0/24
HW HW
*OREDO ,QWHUQHW
,3 QHWZRUN
5RXWHU
LQWHUIDFH QHW LQWHUIDFH QHW
2XWERXQG 7UDQVODWH VRXUFH SRRO WR JOREDO SRRO
