Riverstone Networks RS Switch Router User Guide Release 8.0 30-9
WAN Configuration Monitoring Frame Relay WAN Ports
Note The RS comes with a set of “default values” for Frame Relay interface
configuration settings, which means that setting up a Frame Relay service profile
is not absolutely necessary to begin sending and receiving Frame Relay traffic on
your RS.
After you configure one or more service profiles for your Frame Relay interface(s), you can then apply a service profile
to active Frame Relay WAN ports, specifying their behavior when handling Frame Relay traffic. The following
command line displays all of the possible attributes used to define a Frame Relay service profile:
30.4.3 Applying a Service Profile to an Active Frame Relay WAN Port
Once you have created one or more frame relay service profiles, you can specify their use on one or more active frame
relay WAN ports on the RS. The following command line displays a simplified example of this process:
30.5 MONITORING FRAME RELAY WAN PORTS
Once you have configured your frame relay WAN interface(s), you can use the CLI to monitor status and statistics for
your WAN ports. The following table describes the monitoring commands for WAN interfaces, designed to be used in
Enable mode:
Define a frame
relay service
profile. frame-relay define service [Bc ] [Be ]
[becn-adaptive-shaping ] [cir ]
[high-priority-queue-depth ] [low-priority-queue-depth
] [med-priority-queue-depth ] [red on | off]
[red-maxTh-high-prio-traffic ] [red-maxTh-low-prio-traffic
] [red-maxTh-med-prio-traffic ]
[red-minTh-high-prio-traffic ] [red-minTh-low-prio-traffic
] [red-minTh-med-prio-traffic ] [rmon on | off]
Apply a service profile to an active WAN
port.
frame-relay apply service ports
Display a particular frame relay service profile
frame-relay show service
Display all available frame relay service profiles
frame-relay show service all
Display the last reported frame relay error
frame-relay show stats ports
last-error
Display active frame relay LMI parameters
frame-relay show stats ports lmi
Display MIBII statistics for frame relay WAN
ports frame-relay show stats ports mibII
Display a summary of all LMI statistics
frame-relay show stats ports
summary
