Riverstone Networks RS Switch Router User Guide Release 8.0 28-7
RMON Configuration Configuring RMON Groups
To configure the Filter group, you
must configure both the Channel
and Filter control tables.
rmon channel index port [accept-type
matched|failed] [data-control on|off] [turn-on-event-index
] [turn-off-event-index ] [event-index
] [channel-status ready|always-ready][description
] [owner ] [status enable|disable]
rmon filter index channel-index
[data-offset ] [data ] [data-mask ]
[data-not-mask ] [pkt-status ] [status-mask
] [status-not-mask ] [owner ] [status
enable|disable]
To configure the Etherstats group.
rmon etherstats index port [owner
] [status enable|disable]
To configure the Event group.
rmon event index type none|log|trap|both
[community ] [description ] [owner ]
[status enable|disable]
To configure the History group.
rmon history index port [interval
] [owner ] [samples ] [status
enable|disable]
To configure the Application
Layer and Network Layer Host
groups.
rmon hl-host index port nl-max-entries
al-max-entries [owner ] [status
enable|disable]
To configure the Application
Layer and Network Layer Matrix
groups.
rmon hl-matrix index port nl-max-entries
al-max-entries [owner ] [status
enable|disable]
To configure the Host group.
rmon host index port [owner ]
[status enable|disable]
To configure the Host Top N
entries.
rmon host-top-n index host-index
[base ] [duration ] [size ] [owner
] [status enable|disable]
To configure the Matrix group.
rmon matrix index [port ] [owner ]
[status enable|disable]
To configure the Network Layer
Matrix top n entries.
rmon nl-matrix-top-n index matrix-index
ratebase
terminal-packets|terminal-octets|all-packets|all-octets
duration size [owner ] [status
enable|disable]
