88 P
ARAGON
A
DMINISTRATOR
’
S
I
NSTALLATION AND
O
PERATION
G
UIDE
CIM M
ODEL
:
C
ONNECTION
I
NSTRUCTIONS
:
AUPUSBC
•
Connect DB25 male end of CCUSBnn cable to DB25 female port on
AUPUSB.
•
Connect other end of cable to one of the USB ports and 15-pin video
port on the computer.
UUSBP
•
Connect HD15 video leg attached to UUSBP appropriate 15-pin female
video port on the computer.
•
Connect the UUSBP’s USB leg to appropriate USB port on computer.
UUSBPD
•
Attach the CIM to the computer via its 15-pin male video port,
connecting it to the15-pin female video port on the computer.
•
Connect the UUSBPD’s USB leg to appropriate USB port on computer.
