C HAPTER 3: O PERATING P ARAGON 59
2. Display Ver./SN (Firmware Version and Serial Number): Displays current version of firmware
and unit’s serial number.
F
IRMWARE
: 2C1
SN: CPB80347
Figure 48 Display Ver. and SN
3. Test User UST1 (User Station): Used by administrator to check if user stations (UST1s) are
functioning properly. Press the [] or [] button to change user port number. Display will read
“OK”, “None”, or “Failed. Press [ESC] to return to normal display.
If a “failed” condition is detected, make sure Category 5e UTP cable is installed properly and
secured, or try using another UST1 to see if UST1 under test has become defective.
T
EST
U
SER
UST1
UST1: 3 OK
Figure 49 User Station Test
4. Test Channel UKVM (CIM UKVM): Used by administrator to check if Computer Interface
Module (CIM) is functioning properly. Press the [] or [] button to change channel number.
Display will read “OK”, “None”, or “Failed”. Press [ESC] to return to normal display.
If a “failed” condition is detected, make sure Category 5e UTP cable is installed properly and
secured, or try using another CIM (UKVM) to see if CIM under test has become defective.
T
EST
C
HAN
. UKVM
UKVM: 60 OK
Figure 50 Channel CIM (UKVM) Test
5. Set Bank ID: Press the [] or [] button to ensure that Bank ID is set at “1”. Press [ESC] to
return to normal display.
S
ET
B
ANK
ID
B
ANK
: 1
Figure 51 Set Bank ID
