Perform Channel Configuration:
Paragon recognizes a CIMPac as an extension of a CIM, rather than as a device. As a result, each
server connected to the CIMPac can be configured as a directly connected server would be.
1. On the Selection Menu, viewed in Channel ID number, each green line indicates an active
channel (CIM/computer). Highlight the CIM/server to be selected by using the <Ç>, <È>,
or
2. Normal computer access indicates successful connection. If necessary, adjust the computer’s
video quality by keying on <+> or <–> while in Hot Key mode.
3. Enter a meaningful name for each server (channel):
a.
Press <F5> for Administration Menu and select the Channel Configuration submenu.
b.
On the Channel Configuration Menu, press the <Ç> or <È> keys to highlight the Name
field for channel ID where CIM/computer was just installed.
c.
Press <Enter> - the highlighted area turns light blue.
d.
Edit the server name - highlight turns green as you begin to type - and press <Enter>
when finished.
e.
Press <S> to save the new name.
f.
Press <F2> to return to the Selection Menu and verify that the new name appears on the
Selection Menu in green.
4. Repeat for each CIM/server desired (up to 32).
