CIMPac
The Paragon CIMPac, part number CIMPAC8-RK, expands user access capability to a maximum
of 32 users.
Figure 28 Paragon CIMPac
Installing a CIMPac
These Basic Installation instructions will assist you in creating two Paragon model UMT8 Matrix
Switching configurations with eight users (UST1s) each.
Figure 29 Diagram of Sample Installation for a CIMPac
