C HAPTER 2: I NSTALLATION 35
Connecting a MasterConsole P as a Tier
Note: All tier MasterConsole P models must be MasterView ready. To determine
whether your MasterConsole P model is MasterView ready, check the white label on
the bottom of the unit. Locate unit’s firmware version: MDSP-nnn. If firmware
version is MCSP–1AC or higher (e.g., MDSP-1AD), the unit is MasterView ready.
Some MasterConsole P models that are not MasterView ready can be upgraded to
MasterView Ready. Please contact Raritan Technical Support for details and pricing.
Important: Connecting a MasterConsole P as a Tier is Not Recommended. This
connection should be verified as to the level of user satisfaction prior to continuing.
Note: As a tier device to Paragon, MasterConsole P model can be single bank only.
Connect MasterConsole P to a Base Paragon Switch:
If using a CIM UKVMC:
1. Use a CCPnn cable to connect keyboard, monitor, and mouse connectors of cable into
keyboard, monitor, and mouse ports of MasterConsole P unit.
2. Connect DB25 connector into UKVMC.
If using a CIM UKVMP:
1. Connect keyboard, monitor, and mouse cables to MasterConsole P user port.
2. Connect Category 5e UTP cable to RJ45 port on UKVMP.
3. Connect other end of Category 5e UTP cable to channel port reserved on base Paragon
switch.
Perform Channel Configuration:
1. At the User Station Login Menu type “admin” in the User Name field and press <Enter>.
2. Type “raritan” (all lowercase) in the Password field and press <Enter>.
3. Press <F5> to go to the Administration Menu, then select the Channel Configuration
submenu.
4. Use the <Ç> and <È> or <Page Up> and <Page Down> keys to select a channel in which
MasterConsole P is connected.
5. Press <Tab> to advance to the Device field and change the Device Type to the specific
MasterConsole P model.
6. Hold the <Shift> key and press <Tab> to go back to the Name column.
7. Press <Enter> and edit the Name field.
8. Press <S> to save new configuration.
