Raritan Computer Paragon switch User Manual

Page 57

HAPTER

3: O

PERATING

ARAGON

Selection Menu by Name

Page 1/4
Name Ch. ID

-- ---------------------------------------------------- --------------------------------

MC2-16.Reg1

MX4-Wing.2

NT4.0-Mail

NT4.0-Fax 06

UMT8 Switch-Wing.4

Win95.Bob

X Wins98.Jack

….. Scrolling Messages Banner…..

ScrlLock | Scan | Skip | NCSL

Figure 36 Selection Menu by Name

Note: The <F10> key toggles between showing and not showing all channels on user
OSUI menu . Pressing <F10> will operate only if the Selection Menu is sorted by
Channel ID or if the System Administrator has set the System Configuration Menu
option for “Display All Computers” to Yes. When all channels are visible, the
channel’s scan rate is followed by a red “S,” indicating a group security conflict and
making that computer non-accessible to the user.

1. Press the <Ç> and <È> or <Page Up> and <Page Down> keys to highlight a channel for a

device or computer and press <Enter> to select.
When the Selection Menu is sorted by Channel ID number:
User can press desired computer’s key number (1-8), listed in the left-hand column under No
(Number), and press <Enter> to quickly jump to that channel.
When Selection Menu is sorted alphabetically by Name:
User can type the first character(s) of the desired device name to jump to the device name that
most closely matches the characters typed, and press <Enter>.

Note: A small red triangle on the left of a channel name indicates to which channel
user is currently connected.

If channel represents a computer, the user automatically goes to normal computer operation
and leaves OSUI.

If channel represents a connected MasterConsole device (Two-Tier Configuration), an
additional OSUI Selection Menu for that device is displayed.

To return to the base Paragon Selection Menu from any other level of Selection Menu, press
the <Home> key.

2. Channel switching can be repeated by returning to the OSUI Selection Menu, or by pressing the

Previous Channel key twice rapidly to return to the previously selected channel without seeing
the OSUI.
