68 GBIC specifications
1000BASE-XD GBIC specifications
The 1000BASE-XD GBIC provides Gigabit Ethernet connectivity using SC
duplex single mode fiber connectors. High-performance optical transceivers
enable Gigabit Ethernet link distances of up to 50 kilometers (km) over
single mode fiber. The GBIC operates in full-duplex mode only. The part
number of this GBIC is AA1419003-E5.
CAUTION
To prevent damage to the optical receiver, ensure that at least 3 dB
of attenuation is present between the transmit and receive ports.
The following table describes standards, connectors, cabling, and distance
for the 1000BASE-XD GBIC.
Table 33
IEEE 802.3z 1000BASE-XD GBIC specifications
Parameter Specifications
Connectors Duplex SC single mode
Cabling SMF
Distance Up to 50 km
Link optical power budget 17 dB
Transmitter characteristics
Wavelength 1550 ± 10 nm
Launch power -5.0 to 0 dBm
Receiver characteristics
Wavelength 1200 to 1620 nm
Receiver sensitivity -22 dBm
Maximum input power -3.0 dBm
1000BASE-ZX GBIC specifications
The 1000BASE-ZX GBIC provides Gigabit Ethernet connectivity using SC
duplex single mode fiber connectors. High-performance optical transceivers
enable Gigabit Ethernet link distances up to 70 km over single mode fiber
cable. The GBIC operates in full-duplex mode only. The part number of
this GBIC is AA1419004-E5.
