10 Gigabit small form factor pluggable
transceivers
This section describes how to install and remove 10 Gigabit Small Form
Factor Pluggable (XFP) transceivers, and lists some technical specifications
for the supported XFP models.
ATTENTION
Nortel recommends that you only use Nortel qualified XFPs. If you do choose
to use other vendor XFPs, be aware that Nortel does not support the use of
other XFPs.
Navigation
•
•
•
Selecting an XFP
Use an XFP transceivers to interface a device motherboard to a fiber optic
cable. Select the appropriate transceiver to provide the required reach.
Procedure steps
Step
Action
1
Determine the required reach.
XFPs are available for cable distances of up to 300 meters (m), 10
kilometers (km), 40 km, and 80 km.
2
Determine any wavelength restrictions or requirements.
3
Use the following job aids to determine the appropriate XFP for your
application.
—End—
