100BASE-FX SFP specifications 47
Table 8
General SFP specifications
Parameter Description
Dimensions (H x W x D) 13.4 x 8.50 x 56.4 millimeters (mm)
0.53 x 0.33 x 2.22 inches (in.) unless otherwise
stated
Operating temperature -40 to 80C for RoHS - E6 models
0 to 60C for RoHS - E5 models
Storage temperature -40 to 85C
Maximum supply current 300 mA unless otherwise stated
Maximum power consumption 1.0 W unless otherwise stated
100BASE-FX SFP specifications
The 100BASE-FX SFP provides 100 Mbit/s Ethernet Carrier Sense Multiple
Access with Collision Detection (CSMA-CD) connectivity using multimode
optical fiber. The part number for this model is AA1419074-E6.
The following table describes the 100BASE-FX SFP specifications.
Table 9
100BASE-FX SFP specifications
Parameter Specifications
Maximum electrical power consumption 1.5 W
Connectors Duplex LC
Cabling • 62.5 µm MMF optic cable
• 50 µm MMF optic cable
Distance • Up to 2 km using 500 MHz-km MMF optic
cable
Wavelength 1310 nm
Link optical power budget 10 dB
Transmitter characteristics
Maximum launch power -14 dBm
Minimum launch power -23.5 to -20 dBm
Receiver characteristics
Receiver sensitivity 33.5 dBm
Maximum input power —
Nortel Metro Ethernet Routing Switch 8600
Installation — SFP, XFP, GBIC, and OADM Hardware Components
NN46220-301 01.01 Standard
5.0 1 May 2008
