48 SFP specifications
100-Base LX SFP specifications
The 100BASE-LX SFP provides 100 Mbit/s Ethernet Carrier Sense Multiple
Access with Collision Detection (CSMA-CD) connectivity using single mode
optical fiber. The part number for this model is AA1419081-E5.
The following table describes the 100BASE-LX SFP specifications.
Table 10
100-Base LX SFP specifications
Parameter Specifications
Maximum electrical power consumption 1.5 W
Connectors Duplex LC
Cabling 62.5 µm SMF optic cable
50 µm MMF optic cable
Distance Up to 10 km using 500 Mhz-km MMF optic cable
Wavelength 1310 nm
Link optical power budget 10 dB
Transmitter characteristics
Maximum launch power -14 dBm
Minimum launch power -23.5 to -20 dBm
Receiver characteristics
Receiver sensitivity -33.5 dBm
Maximum input power —
100-Base BX10-U/D SFP specifications
The 100BASE- BX 10-U (upstream) and 100BASE-BX 10-D (downstream)
bidirectional SFP provides 100 Mbit/s Ethernet Carrier Sense Multiple
Access with Collision Detection (CSMA-CD) connectivity. The part number
for the upstream model is AA1419082-E5. The part number for the
downstream model is AA1419083-E5.
The following table describes the 100BASE BX10-U/D SFP specifications.
Table 11
100-Base BX10-U/D SFP specifications
Parameter Specifications
Maximum electrical power consumption 1.5 W
Connectors Duplex LC
Cabling 62.5 µm SMF optic cable
50 µm MMF optic cable
Nortel Metro Ethernet Routing Switch 8600
Installation — SFP, XFP, GBIC, and OADM Hardware Components
NN46220-301 01.01 Standard
5.0 1 May 2008
Copyright © 2008, Nortel Networks
.
