Installing an SFP
25
Model number and connector
Product number
Description
1000BASE-ZX CWDM
AA1419061-E6 to
AA1419068-E6
1470 nm to 1610 nm, up to 70 km
1000BASE CWDM
NTK591LH
NTK591MH
NTK591NH
NTK591PH
NTK591QH
NTK591RH
NTK591SH
NTK591TH
1470 nm, up to 120 km
1490 nm, up to 120 km
1510 nm, up to 120 km
1530 nm, up to 120 km
1550 nm, up to 120 km
1570 nm, up to 120 km
1590 nm, up to 120 km
1610 nm, up to 120 km
1000BASE-BX
AA1419069-E6,
AA1419070-E6
Bidirectional 1310 nm and 1490 nm, up
to 10 km
1000BASE-BX
AA1419076-E6,
AA1419077-E6
Bidirectional 1310 nm and 1490 nm, up
to 40 km
1000BASE-EX
AA1419071-E6
1550 nm, up to 120 km
100-Base FX
AA1419074-E6
1310 nm, MMF, up to 2 km
100-Base LX
AA1419081-E5
1310 nm, SMF, up to 10 km
100-Base BX10-U
AA1419082-E5
1310 nm, bidirectional upstream Tx, up
to 10 km
100-Base BX10-D
AA1419083-E5
1530 nm, bidirectional downstream Tx,
up to 10 km
100-Base ZX
AA1419084-E5
1550 nm, 70 to 80 km
For specifications for these SFPs, see
"SFP specifications" (page 45)
Installing an SFP
Install an SFP to provide an interface between the switch and the network
cable.
Installing an SFP takes about 3 minutes.
SFPs are installed face up in the top row and face down in the bottom row in
modules or ESUs that are equipped with two rows of SFPs.
Prerequisites
•
Verify that the SFP is the correct model for your network configuration.
