54
SFP specifications
Parameter
Specifications
Cabling
SMF, 9 µm
Data rate
1.0 Gbit/s
Line rate (8B/10B code)
1.25 Gbit/s
Operating temperature range
0 to 60C
Link optical power budget
20 dB
Transmitter characteristics
Launch power
-3.0 to 2.0 dBm
Receiver characteristics
Receiver sensitivity
-23 dBm
Maximum input power
-3.0 dBm
1000BASE-SX DDI SFP specifications
The following table describes the 1000BASE-SX DDI SFP, which has a
reach of up to 550 m using 50 µm multimode fiber (MMF), and of 275 m
using 62.5 µm MMF. This SFP operates at 850 nm. The part number of
this SFP is AA1419048-E6.
Table 19
1000BASE-SX SFP DDI (550 m) specifications
Parameter
Specifications
Maximum electrical power consumption
1 watt (W)
Connector
Duplex LC
Cabling
MMF
Data rate
1.0 Gbit/s
Line rate (8B/10B code)
1.25 Gbit/s
Link optical power budget
7.5 dB
Transmitter characteristics
Launch power
-9.5 to -4.0 dBm
Receiver characteristics
Receiver sensitivity
-17 dBm
Maximum receiver power
0 dBm
1000BASE-LX DDI SFP specifications
This SFP can attain a reach of up to 10 km and operates at 1310 nm. The
part number of this SFP is AA1419049-E6.
Nortel Metro Ethernet Routing Switch 8600
Installation — SFP, XFP, GBIC, and OADM Hardware Components
NN46220-301
01.01
Standard
5.0
1 May 2008
Copyright © 2008, Nortel Networks
.
