Windows Setup 4-33
7. Click [OK].
The [Intel(R)PROSet II] dialog box closes after a while, and the settings become effective.
IMPORTANT:
The [Digital signature not found] dialog box may appear (several times). If it
appears, click [Yes].
After setting dual configuration, “Intel(R) Advanced Network Services Virtual
Adapter” will appear on the [Network and dialup connection] or the [Device
Manager] dialog box. Therefore 6 adapters that consist of two “Virtual”, two
“100Base”, and two “1000Base” adapters will appear on the [Network and dialup
connection] or the [Device Manager] dialog box. Do not disable the virtual adapters.
If you disable and enable them again, the system may become unstable and you may
need to restart it.
Set IP address for “Virtual Adapter” after setting dual configuration. Do not specify
IP address for “100Base Adapter” or “1000Base Adapter”.
For dual configuration, use a hub. For AFT function, use a repeater hub or a
switching hub. For ALB function, use a switching hub.
Connect the network cables to the both primary and secondary PCI modules. After
setting of dual configuration, if one network cable is disconnected from a PCI
module or a hub, the status of the PCI modules becomes simplex. In such case, the
status will change to duplex if the network cable is connected to the PCI module or
the hub again.
