5-4 Procedures after Completion of Installation
4. Enter “public” in the [Community name] box in the [Traps] property sheet and click the
[Add to list] button.
IMPORTANT:
To change the community name of traps to be received from the default “*” in
the NEC ESMPRO Manager site, enter the same name as the community name
newly set in the NEC ESMPRO Manager site.
To receive trap from NEC ESMPRO Agent at the NEC ESMPRO Manager
machine, both community names should be the same.
5. Click the [Add...] button in [Trap destinations]. After entering the IP address of the NEC
ESMPRO Manager machine of the send destination in the [Host name, IP or IPX address]
box, click the [Add] button.
IMPORTANT: If the IP address (or host name) of the remote NEC ESMPRO
Manager specified as the trap send destination in the setup of the manager report
(TCP/IP), the message warning the duplication appears. The specification of the
same NEC ESMPRO Manager causes to be reported doubly.
6. Open the [Security] property sheet and make settings as follows;
• Add the community name entered in Step 4 to [Accepted community names].
•
Set its authority to [READ CREATE] or [READ WRITE].
• Select [Accept SNMP packets from any host.]
IMPORTANT:
If you entered any community name other than “public” in Step 4, add that
name to “Accepted community names”.
Unless you set the acceptable community’s authority to “READ CREATE” or
“READ WRITE,” you cannot perform monitoring from NEC ESMPRO
Manager.
< Setup of receiving SNMP packets from specific hosts only >
Select [Accept SNMP packets from these hosts], specify IP addresses of the hosts, IP
addresses of the servers to install Agent, and the loop-back address (127.0.0.1).
< Setup of receiving SNMP packets from specific communities only >
Change the name of the community receiving SNMP packets from the default “public”
to any name.
